MATRIX MPS-200 Programmable DC Power Supply (0-32V, 0-6A, 192W)

Rated input voltage: AC220V/110V±10%

Rated output voltage: 0-32V

Rated output current: 0-6A

Rated output power: 192W

Load regulation rate: ≤0.02%+5mV / ≤0.02%+5mA

Line regulation rate: ≤0.02%+5mV / ≤0.02%+5mA

Setting resolution: 1mV / 0.1mA

Read back resolution: 1mV / 0.1mA

Setting accuracy (25℃±5°C): ≤0.1%+8mV / ≤0.2%+2mA

Read back accuracy (25℃±5°C): ≤0.1%+8mV / ≤0.2%+2mA

Ripple and noise (25℃±5℃): <8mVms / <3mArms

Temperature coefficient

+ Operating: 0 to 40°C, ≤ 80R.H

+ Storage: -15 to 70°C ≤ 80R.H

Machine size(W*H*D): 111*170*250 mm

Net weight: 2KG

The MPS-200 series can be widely used in electronic product development, component testing, communication industry, laboratories, research institutions, etc.
