Mark-10 M7-5 Professional Digital Force Gauges (5 lbF / 80 ozF / 2.5 kgF / 2500 gF / 25 N)

Capacity x Resolution: Force gauge, 5 lbF / 80 ozF / 2.5 kgF / 2500 gF / 25 N

Accuracy: ±0.1% of full scale

Sampling Rate: 14.000 Hz, pulse response of 1/7.000 sec. minimum

Power:

AC adapter: 100-240VAC, 50-60 Hz, 0.3 A

Battery: Rechargeable 8.4V NiMH

Battery life: Backlight on / off: up to 7 / 24 hours of continuous use

Outputs:

USB / RS-232: Configurable up to 115.200 baud. Automatic output available up to 250 Hz. Includes Gauge Control Language 2 for full computer control

Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC compatible devices

Analog: ±1 VDC, ±2% of full scale at capacity

General purpose: Three open drain outputs, one input

Set points: Three open drain lines

Safe overload: 200% of full scale (display shows “OVER” at 110% and above)

Weight: 1.0 lb [0.45 kg]

Load cell deflection: 0.010 [0.25]

Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensating
