Mark-10 M5-2000 Advanced Digital Force Gauges (2000 lbF / 32000 ozF / 1000 kgF / 10000 N / 10 kN)

Capacity x Resolution: Force gauge, 2000 lbF / 32000 ozF / 1000 kgF / 10000 N / 10 kN

Accuracy: ±0.1% of full scale

Sampling Rate: 7.000 Hz

Power: AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low

Battery: Backlight on: up to 7 hours of continuous use / Backlight off: up to 24 hours of continuous use

Outputs:

USB / RS-232: Configurable up to 115.200 baud. Includes Gauge Control Language 2 for full computer control

Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.

Analog: ±1 VDC, ±2% of full scale at capacity

General purpose: Three open drain outputs, one input

Set points: Three open drain lines

Configurable settings: Digital filters, outputs, automatic output (via USB/RS-232), automatic shutoff, default settings, averaging mode, external trigger, passwords, key tones, audio alarms, backlight, calibration

Safe overload: 200% of full scale (display shows “OVER” at 110% and above)

Weight (lb [kg]): 1.8 [0.82]

Environmental requirements: 40 - 100°F, max. 96% humidity, non-condensating
