Mahr MarSurf VD 280 BG 12 Roughness and Contour Measuring Station (X 280mm, Z 350mm)

Start of traversing length (in X):0 mm

End of traversing length (in X):280 mm

350 mm Z-axis

With angle adjustment of the X-axis

Positioning speed: 0.02 – 200 mm/s (in X)

Guide deviation:0.07 µm / 20 mm (with probe system BFW 250),0.35 µm / 60 mm,0.4 µm / 140 mm

Measuring speed: Up to 10 mm/s

Measuring range:

- With probe system BFW 250:

500 µm (±250 µm) for probe arm length 45 mm

1500 µm (±750 µm) for probe arm length 135 mm

- With probe system C 11:

70 mm with probe arm length 350 mm

max. 100 mm with probe arm length 490 mm

ACCESSORIES

Optional

•  Manual control panel with joystick and display

•  Motor-driven TY axis

•  Parallel vice

•  Prism block

•  Equipment table

•  Vibration damping system

General software options

•  Option - MeasurementPlus

•  Option - RoughnessPlus

•  Option - ContourPlus

•  Option - Dominant Waviness (WDc) for MarWin

•  Option - ISO 13565-3 surface parameters

•  Option - QS-STAT / QS-STAT Plus

•  Option - Profile processing

•  Option - User-defined parameters

•  Option - Topography
