MAETALL LMP-4SC Grinding and Polishing Machine

Disc diameter: φ250mm (customized φ230mm, φ300mm)

Disc rotation speed: 50-1000 r/min (variable speed) and 300 / 600 / 900 r/min (3 fixed speed), step 1r/min

Motor quantity: double disc single control with one motor, double disc are controlled with two motors

Display: LCD touch screen control on the polishing head

Data storage: Preset program, and can save other settings

Disc rotation direction: Clockwise and counter clockwise

Water supply control: Automatic

Polishing head rotation speed: 5-150 r/min (variable speed), step 1r/min

Number of samples prepared: 6pcs

Fix paper, cloths and diamond discs by magnetic system and ring

Sample diameter: factory standard φ30mm(diameter φ22-φ45mm can be customized)

Pressure loading: Individual and central pressure loading Individual and centrol pressure force, adjustable force of at least 5-400N step 1N

Sampling time: 0-3000 S

USB - for software updates and for connecting a flash card.

Connector for remote connection and service.

Input voltage: single-phase AC220V 50Hz

Total power: 900W

Dimension: 815*690*755mm

Net weight: 90KG

Gross weight: 120KG

Dropper:

Four channels are set separately and work at the same time

Connect with the polishing machine, and drop liquid according to the polishing parameters set by the polishing machine

Three working modes: Manual/Online/Fully automatic

Each mode can be set independently: dripping speed, drippingtime

Instillation speed: about 6 drops/minute-280 drops/minute

Maximum flow rate: 18 ml/min

Speed adjustment: stepless speed adjustment, from 6 drops/minute to 280 drops/minute
