MACOM MAATCC0009 Digital Attenuator DC-4GHz 31.5dB .5dB steps 6-Bit
ManufacturerMACOM(View more products from this manufacturer)
ModelMAATCC0009
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
Width: 4 mm
Height: 0.9 mm
Length: 6 mm
Impedance: 50 Ohms
Tolerance: 0.5 dB
Technology: GaAs
Attenuation: 31.5 dB
Unit Weight: 368.800 mg
Maximum VSWR: 2.2
Power Rating: 34 dBm
Insertion Loss: 5.1 dB
Mounting Style: SMD/SMT
Number of Bits: 6 bit
Maximum Frequency: 4 GHz
Minimum Frequency: DC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Attenuator Step Size: 0.5 dB
Operating Supply Voltage: 5 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
