MACOM MA4FCP200 Pin Diode .1-40GHZz Cj=.02pF TL 100ns

Technology: Si

Unit Weight: 185 mg

Carrier Life: 100 ns

If - Forward Current: 100 mA

Ir - Reverse Current: 10 uA

Vf - Forward Voltage: 1.25 V

Vr - Reverse Voltage: 70 V

Pd - Power Dissipation: 100 mW

Maximum Diode Capacitance: 0.02 pF

Maximum Operating Frequency: 40 GHz

Minimum Operating Frequency: 100 MHz

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 55 C

Maximum Series Resistance @ Maximum IF: 2.8 Ohms
