Ludatest TSY-2000B Fully Automatic Compression Testing Machine (2000kN)

Description:

Compressive strength test of brick, cement mortar, concrete and other building materials. It can also be used for mechanical properties test of other materials. The computer controls the lifting of the machine screw without manual operation. Semi-automatic compression testing machine adopts hydraulic loading, electronic force measurement, with load digital display, maximum load maintenance and power-off data protection functions. Automatic test data processing and printing out test reports.

Specification:

Max Test Force: 2000 kN

Measure Range: 5-100 %

Load Indication Accurancy: ±1/±0.5 %

Max Pressing Space: 320 mm

Bearing Plate Diameter: 300*260 mm

Oil Pump Motor Power: 0.75 kw

Control Cabinet: 470*600*1500 mm

Net Weight: 900 kg
