LS ABS803c 630A Moulded Case Circuit Breaker (3P, 630A, 75kA)

Number of poles: 3P

Frame size: 800AF

Line voltage: AC, DC

Rated voltage (Ue): 500VDC, 690VAC

Rated frequency: 50Hz, 60Hz

Current rating adjustable (Ir): No

Rated current (In): 630A

Characteristics curves: C

Rated short-circuit breaking capacity (Icu): 8kA at 690VAC, 35kA at 480VAC, 50kA at 415VAC, 65kA at 380VAC, 75kA at 220VAC, 20kA at 500VDC, 20kA at 250VDC, 35kA at 500VAC, 50kA at 460VAC, 75kA at 250VAC

Service breaking capacity - Ics (% Icu): 100%

On/Off control type: Handle toggle

Mounting method: Surface mounting

Connection type: Screw terminals

Approx. weight: 8.8kg

Overall width: 210mm

Overall height: 280mm

Overall depth: 145mm
