Longer BT100-3J Basic Peristaltic Pump (380mL/min)

Max Flow Rate (Single Channel): 380 mL/min

Speed Range: 0.1–100 rpm (CW/CCW)

Speed Resolution: 0.1 rpm

Display: 3-digit LED display for current speed

Work Mode: Continuous mode

Control Mode: Keypad control; Footswitch control; External control; Communication control

External Control: Start/stop; running direction; speed

Communication Control: RS485

Calibration: N/A

Dimensions (L × W × H): 232 × 142 × 149 mm

Power Supply: AC 100–240 V, 50/60 Hz

Operating Temperature: 0 ~ 40 °C

Relative Humidity: < 80%

IP Rating: IP20

Weight: 2.3 kg

Acceptable pump heads for BT100-3J are YZ1515x,YZ2515x,YZII15, YZII25, DG, BZ, DG15 and DMD15-13.

The pump delivers flow rates from 0.0002 to 380 mL/min.

The speed can be adjusted manually or automatically through external control interface.

Store the running parameter automatically.

Easy to operate.

CE marking.
