Littelfuse SK008DRP SCRs 8A 1000V

Width: 6.2 mm

Height: 2.39 mm

Length: 6.63 mm

Features: Glass passivated Chip junction

Unit Weight: 1.800 g

REACH - SVHC: Details

Current Rating: 8 A

Mounting Style: SMD/SMT

Vf - Forward Voltage: 1.6 V

Holding Current Ih Max: 30 mA

Breakover Current IBO Max: 100 A

Gate Trigger Current - Igt: 15 mA

Gate Trigger Voltage - Vgt: 1.5 V

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

On-State RMS Current - It RMS: 8 A

Non Repetitive On-State Current: 100 A

Off-State Leakage Current @ VDRM IDRM: 20 uA

Rated Repetitive Off-State Voltage VDRM: 1 kV
