Littelfuse MHP-TAC15-12-90N Metal Hybrid Protection Breakers MHP-TAC15-12-90N

Width: 2.9 mm

Height: 0.85 mm

Length: 4.85 mm

Approvals: UL, cUL

Tolerance: +/- 5 C

Resistance: 5 mOhms

Width - in: 0.11 in

Width - mm: 2.8 mm

Length - in: 0.19 in

Length - mm: 4.75 mm

Hold Current: 15 A

Contact Rating: 12 VDC / 25 A, 6000 cycles

Rated Temperature: + 90 C

Reset Temperature: > 40 C

Maximum Temperature: + 90 C

Maximum Leakage Current: 150 mA

Minimum Holding Voltage: 3 V

Maximum Breaking Current: 5 VDC / 80 A, 100 cycles

Maximum Operating Temperature: + 100 C

Minimum Operating Temperature: - 30 C
