Lisun JL-UL UL Water Spray Test Device (50-150 Kpa, >10L/min)

• Outside dimensions of equipment: 1500*800 mm (Length* Width)

• The height adjustable range of equipment:1000-2000 mm

• Number of nozzles: 4

• The distance between the sprinkler junction and the ground: 0-1000 mm

• The spray angle of the lower nozzle: 45 degrees (horizontal direction)

• Flow rate: >10L/min

• Total flow pressure: 50-150 Kpa

• Single nozzle pressure: 34.5 Kpa

• Number of pressure gauges: 5
