Lisun HM-700 Haze and Transmittance Measurement (CIE-A,CIE-C,CIE-D65 / 0-100%)

Light Source: CIE-A,CIE-C,CIE-D65

Standards: ASTM D1003/D1044, ISO13468/ISO14782

Parameters: HAZE,Transmittance(T)

Spectral Response: CIE Luminosity function y

Wavelength: 400-700nm

Wavelength: Interval 10nm

Geometry: 0/d

Measurement Area/Sample Port: 16.5mm/21mm

Measurement Range: 0-100%

Haze Resolution: 0.01

Haze Repeatability: ≤0.1

Sample Size Thickness: ≤150mm

Display: 5 inch TFT LCD screen

Memory: 20000 value

Interface: USB

Power: 220V (with power cable)

Working Temperature: 10-40 ℃

Storage Temperature: 0-50℃

Size (LxWxH): 598mm X 247mm X 366mm

Standard Accessory: PC software (Color QC)

Optional: Measurement Fixture, Haze standard film

Datasheet

Application:

Plastic sheet, film, glass, screen, etc.
