Frequency: 15kHz
Power: 4200W Landing type
Input Voltage: AC220V
Cylinder Size (mm): 125 × 100
Machine Journey: 392mm
Output Time: 0.01-9.99s
Air Pressure: >1, ≤7bar
Welding Capability: Φ350mm
Operation Switch: Two-hand release, emergency stop button at the front, and adding external control switch supported.
Dimension (Press): 965 × 785 × 2185 mm
Dimension (Generator): 820 × 750 × 210 mm
Net Weight (Press): 280kg
Net Weight (Generator): 40kg
