Minimum Size Detection: 0.3 μm
Standard 2 Channels (4-20mA): 0.3, 0.5 μm
Optional 2 Channel (4-20mA): 0.3, 0.7; 0.3, 2.0; 0.3, 3.0 μm
Standard 4 Channels (Modbus): 0.3, 0.5, 0.7, 1.0 μm
Optional 4 Channels (Modbus): 0.3, 0.5, 1.0, 3.0 μm
Flow Rate: 100 mL / minute
Coincidence error: 4,000 counts/ml @ 5%
Sample Pressure: 150 PSI
Sample Temperature: 32 - 140°F (0 - 60°C)
Sample Inlet/Outlet Connection: 1/4” FlaretekTM
Laser Source: Laser Diode
Calibration: NIST Traceable
Wetted Surface Materials: Quartz, PTFE, PFA
Data Storage: Rotating buffer 2,000 records (modbus models)
External Alarm Output: Normal open dry contact rated 0-60v AC/DC 1 Amp
Communication Modes: RS232/485 via RJ45 to PC, RS485 modbus, ASCII, Modbus or MR protocol
LED Indicators: Power, Sampling (4-20mA model); Power, Service, Sampling (485 modbus model)
Power: 24 VDC
Dimensions: 5.7”(l) x 5.2”(w) x 3.0”(h) [14.47 x 13.2 x 7.6 cm]
Weight: 3.5 lbs (1.58 kg).
Includes: Power supply; tubing; flow cell cleaning, brush with Micro90 cleaning solution.
