Lighthouse Remote 1100LD Airbone Particle Counter (0.1 - 1.0μm, 1.0 CFM)

Minimum Size Detection: 0.1 μm

Standard 8 channel sizes: 0.1, 0.15, 0.2, 0.25, 0.3, 0.5, 0.7,1.0 μm

Communication: Serial - 485 Modbus RJ45

Modbus Protocols: Serial or ASCII

Software: LMS Express, LMS Pharma, LMS Pro and LMS Xchange

Flow Rate / Nozzle Size: 1 CFM (28.3 LPM), 1/4” fittings

Concentration Limits: 1,000,000 Particles/ft3@10% Coincidence loss suitable for ISO classes 1-8 cleanrooms

Data Storage Records: 999

Self Diagnostics: laser current, background voltage

Enclosure: 304 Stainless Steel

Power: 24 VDC

External Vacuum Requirements: Nominal 1.0 CFM 18" (45.72 cm) of Hg

Light Source: Extreme Life Laser Diode

Calibration: ISO 21501-4 Compliant and Accredited ISO 17025

Zero Count Level: < 1 Count / 5 minutes (meets specifications of JIS B 9921 and reporting requirements of ISO 21501-4 Annex C)

Dimensions: 10.5” (w) x 7.65” (h) x 3.35” (d); [26.67 x 19.43 x 8.51 cm]

Includes: 24 VDC power adapter and power cord, Calibration Certificate, Purge Filter

Optional: Temperature & humidity probe, 1 CFM isokinetic sample probe, 0.1 CFM isokinetic sample probe, Beveline tubing, printed operators manual
