Minimum Size Detection: 0.3 μm
Standard 6 Channel sizes: 0.3, 0.5 , 1.0 , 2.5, 5.0, 10.0 μm
Flow Rate: 0.1 CFM (2.83 LPM)
Weight: 2.2 lbs (1 kg)
Concentration Limits: 8,000,000 Particles/ft3@10% Coincidence loss
Communication: RS-232 via RJ-45 to PC or optional printer
Count Modes: Automatic, manual, beep, concentration, cumulative/differential
Data Storage Records: 3,000 sample records, rotating buffer, includes particle and environmental data, location, and time
Alarms: Internal, adjustable alarm on counts, low battery, sensor failure
Sample Inlet: Isokinetic sampling probe
Sample Outlet: Internally filtered to HEPA standards (>99.97% @ 0.3 μm)
Vacuum Source: Internal pump, automatic flow control
Environmental Sensors: Direct Mount Temperature/Relative Humidity probe: 0-150°F (-17.8 to 65.6°C)±1.8°F@77°F, 0-100% ± 5%@33%
Enclosure: High impact injection molded plastic
Power: External power supply: 12 VDC, 1.25 A
Battery: Li-Ion, removable and rechargeable
Light Source: Extreme Life Laser Diode
Calibration: ISO 21501-4 Compliant and Accredited ISO 17025
Zero Count Level: < 1 Count / 5 minutes (meets specifications of JIS B 9921 and reporting requirements of ISO 21501-4 Annex C)
Dimensions: 8.75“ (l) x 5.0” (w) x 2.5” (h), (22.23 x 12.70 x 6.35 cm)
Software: LMS Express, LMS Express RT, LMS Pharma, LMS Pro, LMS Xchange
Languages: English (U.S.), Deutsch, Espanol, Italiano, Français, Russian, Japanese, Korean and Chinese
Includes: Removable battery, direct mount insokinetic sample probe; purge filter; temperature/relative humidity probe; power supply; power cord
Optional: Carry Case, Isokinetic sample probe with 6ft tubing, additional Li-Ion batteries, external battery charger w/AC & car adapter, thermal printer
and printer cable, printed operating manual
