Leeb 432 Surface roughness tester (Ra:0.005-16μm Rz:0.02-160μm; 0.001μm)

Roughness parameter: Ra、Ry、Rq、Rz、Rt、RSm、RS、Rp、Rv、R3z、RSk、Rmax、Rmr

Measuring range: Ra:0.005-16μm Rz:0.02-160μm

Resolution: 0.001μm

Cut-off lengths: 0.25mm / 0.8mm / 2.5mm

Evaluation length: 1.25mm / 4mm / 5mm

Accuracy: ≤±6%

Repeat ability: <6%

Sensor: Piezocrystal

Power supply: 3.7V Lithium-Ion battery

Operating temperature: 0 ºC -40 ºC

Weight: 440g

Dimensions: 119×47×65mm

Standard configuration

Main Unit,Standard sensor,Model for multi-standard groove,Power adapter

Optional Accessories: Measurement Platform, printer ,PC analysis software
