Leadfluid BT600S Basic Variable Speed Peristaltic Pump (0.16～2900mL/min, 1 CH)
Specifications
Flow range: 0.16～2900 mL/min
Speed range: 0.1-600 rpm
Speed resolution: between 0.1-100 rpm, 0.1 rpm resolution; between 100-600 rpm, 1 rpm resolution
Speed accuracy: 0.2%
Power supply: AC 100-240V, 50Hz/60Hz
Power consumption: < 60W
External logic level control signal: 5V, 12V (standard), 24V (optional)
External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)
Communication interface: RS485 MODBUS interface
Operating condition: Temperature 0-40°C; Relative humidity < 80%
IP grade: IP31
Dimensions (L x W x H): 264 x 150 x 270mm (10.37 x 5.91 x 10.63 inch)
Weight: 5.2 kg (11.5 lbs)
BT600S Suitable Pump Heads and Tubings, Flow Parameters
| Drive type | Pump head | Ch | Tubing size | Flow rate per channel (mL/min) |
| BT600S | YZ15 | 1 | 13# 14# 16# 19# 25# 17#18# | 0.006-2300 |
| YZ25 | 1 | 15# 24# | 0.17-1700 | |
| 2 x YZ15 | 2 | 13# 14# 16# 19# 25# 17#18# | 0.006-2300 | |
| 2 x YZ25 | 2 | 15# 24# | 0.17-1700 | |
| DT15-24 | 2 | 19# 16# 25# 17# | 0.07-2240 | |
| YT15 | 1 | 13# 14# 16# 19# 25# 17# 18# | 0.006-2300 | |
| YT25 | 1 | 15# 24# 35# 36# | 0.17-2900 | |
| 2 x YT15 | 2 | 13# 14# 16# 19# 25# 17# 18# | 0.006-2300 |
Above flow parameters are obtained by using silicone tube to transfer pure water under normal temperature and pressure, in actually it is effected by specific factors such as pressure, medium, etc. Above for reference only.
