Leadfluid BT102S Basic Variable-Speed Peristaltic Pump (0.00011-720mL/min, 4 ch)

Specifications

Flow range: 0.00011-720 mL/min

Speed range: 0.1-150 rpm

Speed resolution: 0.1-100 rpm, 0.1 rpm resolution; 100-150 rpm, 1 rpm resolution

Speed accuracy: 0.5%

Power supply: AC 220V ± 10% 50Hz/60Hz; AC 110V ± 10% 50Hz/60Hz

Power consumption: < 40W

External logic level control signal: 5V, 12V (standard), 24V (optional).

External analog control signal: 0-5V (standard); 0-10V, 4-20mA (optional)

Communication interface: RS485 MODBUS

Operating condition: Temperature 0~40°C; Relative humidity <80%

IP grade: IP31

Dimensions (L x W x H): 226 x 150 x 238 mm (8.90 x 5.91 x 9.37 inch)

Weight: 4.7 kg (10.4 lbs)

BT102S Suitable Pump Heads and Tubings, Flow Parameters
