Ports: ¼ FNPT
Leak Rate Certification: 2 x 10⁻⁸ atm cc/sec Helium
Body Material: Stainless Steel 316L
Diaphragm: Stainless Steel 316L
Main Valve: Stainless Steel 316L
Valve Spring: Stainless Steel 316L
Valve Seat: Teflon
Max Inlet Pressure: 3500 psig (238 bar)
Max Outlet Pressure: 145 psig (10 bar)
Operating Temperature: -40°C to +70°C (-40°F to +158°F)
Flow Capacity: Cv 0.06
