Lattice Semiconductor LAE5UM-45F-6BG381E FPGA - Field Programmable Gate Array Lattice ECP5 Auto Grade (AEC-Q100), 43.8K LUTs, 1.1V, SERDES

Unit Weight: 10.200 g

Total Memory: 1944 kbit

Qualification: AEC-Q100

Mounting Style: SMD/SMT

Number of I/Os: 203 I/O

Distributed RAM: 351 kbit

Embedded Memory: 1.9 Mbit

Moisture Sensitive: Yes

Supply Voltage - Max: 1.155 V

Supply Voltage - Min: 1.045 V

Embedded Block RAM - EBR: 108

Number of Logic Elements: 44000 LE

Operating Supply Voltage: 1.1 V

Maximum Operating Frequency: 400 MHz

Adaptive Logic Modules - ALMs: 22000 ALM

Maximum Operating Temperature: + 125 C

Minimum Operating Temperature: - 40 C

Number of Logic Array Blocks - LABs: 5500 LAB
