Maximum Package
Dimensions:
Length 48 in. (122 cm)
Width 48 in. (122 cm)
Height 78 in. (198 cm)
Contact Lansmont for larger configurations.
Verified Force Range: 1,500 - 15,000 lbs. (6.67 - 66.7 kN)
Contact Lansmont for extended range options
Positioning Speeds: Cross-head 16 ft./min.(4.88 m/min.)
Test speed 0.5 in./min. (1.27 cm/min.)
Testing Modes:
Constant deflection rate
Ramp to load and release
Load profile simulation
Deflection profile simulation
