LANScientific YANG 700F Food Heavy Metal Rapid Analyzer

Size: 418 × 330 × 173mm

M-DCPS: Air-cooled X-ray tube

X-ray tube target: Ni, Mo, Ag, W target (optional)

X-ray tube voltage: max. 50kV and the equivalent rate of X-ray radiation measurement is＜ 0.2μSv/h

X-ray tube power: 0-50W

Crystal: Hyperboloid curved crystal

Detector: Stage 2 Peltier refrigeration SDD detector

Scope of element: Mg-U

Battery: lithium battery

Working temperature: -20℃~50℃

Working humidity: 20%~90%RH

Data output: USB, Bluetooth, GPS, 4G communication

Measuring time: 30-1800s optional

Resolution: Optimal 125 ev

Weight: 12KG

Analysis language: Based on the I. MX 6 Quad quad-core Cortex-A9 processor, 80MHz ADC digital pulse processor, 4096 MCA channel, 32 GB memory
