LANGER EMV-Technik ICI-DP HH150-15 set Double Pulse Magnetic Field Source set (150 μm)

Probe head dimensions:: Ø 150 µm

Pulse parameter:

Rise time: 2 ns

Min. double pulse sequence time: 25 ns (200 V)

Polarity (set by software): +/-

Voltage: 50 - 1000 V

max. Jitter (typ.): ± 1 ns

Min. trigger pulse delay: 35 ns

Scope of delivery

1xICI-DP HH150-15, Double Pulse Magnetic Field Source

1xBPS 204, Burst Power Station

1xBPS 204-Client, BPS 204-Client Software

1xHV FI-FI mini 1 m, High-Voltage Cable, Fischer-Fischer

1xSK FI-FI 7P 1 m, Control Cable, Fischer-Fischer

1xSMA-SSMB 1 m, SMA-SSMB Measuring Cable

1xNT FRI EU 24V, Power Supply Unit

1xUSB-AB, USB Cable Type A-B

1xICI-DP case, System case

1xICI-DP m, ICI-DP set User Manual

1xBPS 204 m, BPS 204 User Manual

1xICI-DP qg, Quick Guide
