LabTech MultiVap 96 Concentrator – Solution for Microplates

TECHNICAL FEATURES

Number of positions: Up to 96 positions

Heating technique: Advanced direct nitrogen heating with higher efficiency than bottom dry block heating

Heating performance: Improved heating uniformity and faster heating time

Control interface: Touch display with intuitive interface for temperature, time and flowrate control

Program memory: 4 program methods can be saved and loaded

Plate holder height: Adjustable height for 96-well plate holder

Plate movement: Auto lift up/down of the 96-well plate

Needle maintenance: Removable nitrogen needles for easy cleaning

Nitrogen pressure control: Adjustable nitrogen purge pressure according to sample requirements

Nitrogen flowrate control: Adjustable flowrate according to different samples

Timer range: 1 ~ 9999 min

Gas flowrate: 0 ~ 20 L/min

Temperature range: Ambient to 80°C

Temperature control accuracy: ±3°C

Weight: 11 kg

Dimensions (L × W × H) cm: 16.9 × 33 × 37.1

Power supply voltage: 230V 50/60Hz

INCLUDED

Gas line adapter: N° 1 – Ø6–Ø8

Gas tube: N° 1 – Ø6, 3 m

Pressure regulator: N° 1

Power cord: N° 1

Spare gas needles: N° 4
