KYOCERA AVX 008263021200000+ Shrouded 2P STRAIGHT THT PLUG NATURAL 2.5mm

Pitch: 2.5 mm (0.098 in)

Application: Wire-to-Board

Unit Weight: 199.443 mg

Housing Color: White

Latching Type: Friction Lock

Contact Gender: Pin (Male)

Current Rating: 3 A

Mounting Angle: Straight

Mounting Style: Through Hole

Number of Rows: 1 Row

Voltage Rating: 250 V

Contact Plating: Tin

Contact Material: Copper Alloy

Housing Material: Thermoplastic (TP)

Termination Style: Solder Pin

Mating Post Length: 5.5 mm (0.217 in)

Flammability Rating: UL 94 V-0

Number of Positions: 2 Position

Termination Post Length: 3.6 mm (0.142 in)

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 20 C
