Kongter DLB-2230 Battery Load Banks (220V,300A)

Power supply: AC220V or AC110V, 50/60Hz;

Cell type

1) Standard: 1.2V1, 2V, 6V and 12V

2) Customized: 12V ONLY or other uncommon battery types.

Discharge voltage range: 10V-264V with constant current in this ranges:(Constant current of 300A in the range of 198V-264V)

Discharge current range:

Single load bank: 0-300A

Parallel loads: 0-1500A (up to 5 loads)

Parallel load with other models of same rated voltage of 220V.

Accuracy:

Current: 1%

Voltage: 0.5% – 0.8%

Resolution

Current: 0.1 A or 0.5%

Voltage: 0.001 V

Sampling interval: 5s –1min

Discharge pattern: Constant current discharge

Display: 128*64 pixel, 5” TFT touch screen (resistive screen)

CDL power supply: 9~36Vdc

CDL measurement range: 0~15Vdc

Data transfer: USB, Wifi (for CDL to load bank and PC)

Cooling: Forced air cooling

Operation temperature: 0℃～40℃ (32 – 104 °F)

Humidity: 5%～90% Relative humidity

Standard: CE marking, EMC standard

Main unit dimension: 440*1025*650mm

Main unit weight: 75kg
