Koehler K46195 Cloud and Pour Point Chamber (3-bath)

Cloud point and pour point are indicators of the lowest temperature of utility for petroleum products.

Specifications

- Conforms to the specifications of:

ASTM D97, D2500, D5853, D6074, D6158; IP 15, 219; ISO 3015, 3016; DIN 51597; FTM 791-201; NF T 60-105

Electrical requirements: 220-240V 50Hz, Single Phase, 6.9A

Net weight: 200 lbs (90.7kg)

Shipping information

- Shipping weight: 299 lbs (135.6kg)

- Dimensions: 32x28x34 in. (81.3x71.1x86.4cm)

Additional accessories

- 332-004-001 Test Jar Clear, flat bottom jar with sample height graduation

- 250-000-05F ASTM 5F Thermometer, range: –36 to +120°F

- 250-000-05C ASTM 5C Thermometer, range: –38 to +50°C

- 250-000-06F ASTM 6F Thermometer, range: –112 to +70°F

- 250-000-06C ASTM 6C Thermometer, range: –80 to +20°C

- K46120 Cork Disk

- K46130 Foam Sponge Disc

- AS568-219 Gasket, for test jar

- K460-0-8 Thermometer Holder, for test jar

- K460-1-7B Copper Jacket
