Koehler K18295 Water Spray Apparatus (1⁄3hp, 1725rpm)

Evaluates the ability of a lubricating grease to adhere to a metal surface when subjected to a direct water spray under controlled conditions.

Specifications

- Conforms to the specifications of: ASTM D4049 Circulation System

- Drive motor: 1⁄3hp, 1725rpm

- Pump: rotary gear positive displacement type

- Pressure gauge: 0-60psi

- Temperature control stability: ±1°F (±0.5°C)

Electrical requirements: 220-240V 50Hz, Single Phase, 6.8A

Dimensions

- lxwxh,in.(cm): 29x18x331⁄2 (74x46x85)

- Net weight: 110 lbs (49.9kg)

Shipping information

- Shipping weight: 210 lbs (95.3 kg)

- Dimensions: 35x25x38 in. (88.9x63.5x96.5cm)

Included accessories

- Stainless steel test panel

- Grease application fixture

Additional accessories

- 250-000-37C ASTM 37C Thermometer, Range: –2 to +52°C

- K18210 Stainless Steel Test Panel

- K18220 Grease Application Fixture

Datasheet

Manual
