Kinetic Technologies KTD2801ECD-TR High Efficiency Step-up LED Driver with internal Diode, PWM/ExpressWire Control (36V OVP)

Dimming: With Dimming

Features: PWM Dimming, Open LED Protection

Topology: Boost

Output Type: Constant Current

Unit Weight: 8.450 mg

Input Voltage: 2.7 V to 5.5 V

Mounting Style: SMD/SMT

Output Current: 20 mA

Output Voltage: 36 V

Number of Outputs: 1 Output

Number of Channels: 1 Channel

Input Voltage - Max: 5.5 V

Input Voltage - Min: 2.7 V

Operating Frequency: 1 MHz

Supply Current - Max: 1.65 mA

Pd - Power Dissipation: 1.54 W

Maximum Operating Temperature: + 85 C

Minimum Operating Temperature: - 40 C
