KIKUSUI PMX32-2QU Multi-output DC Power Supply (4CH, 32V/3A, 18V/2.5A)

Input voltage: 217 VAC ± 10% , 800VA

Constant voltage (CV):

+ Output:

CH1: 32V

CH2: 32V

CH3: 18V

CH4: 18V

+ Ripple: 500 µV

+ Line regulation:

CH1: 3 mV

CH2: 3 mV

CH3: 1 mV

CH4: 1mV

+ Load regulation:

CH1: 2 mV

CH2: 2 mV

CH3: 3 mV

CH4: 3 mV

Constant current (CC):

+ Output:

CH1: 2A

CH2: 2A

CH3: 2.5A

CH4: 2.5A

+ Ripple:

CH1: 1 mA

CH2: 1 mA

CH3: 1 mA

CH4: 1 mA

+ Line regulation: 0.01% + 0.25 mA

+ Load regulation: 5 mA

Protection function: overvoltage, overcurrent, overheat

Interface: RS232C, USB, LAN, GPIB (option)

Weight: 13 kg (28.66 lbs)

Accessories: Power cord, packing list, ouput terminal cover set, safety information, CD-ROM
