• Input ratings: 0–120A; 0–60V; 600W
• CC mode:
Low range/Accuracy: 12A / 0.1%+15mA
High range/Accuracy: 120A / 0.1%+37.5mA
• CV mode:
Low range/Accuracy: 6V / 0.1%+3mV
High range/Accuracy: 150V / 0.1%+20mV
• CR mode: 0.017–1Ω at range > 10% of current rating
• Ripple and noise (20 Hz–10 MHz): 6mA/60mA (rms/peak to peak); 8 mV rms
• Interface: GPIB
• Net weight: 4.6 kg (10 lb)
