KEYSIGHT E5063A ENA Vector Network Analyzer (Body only)

• Frequency: 18 GHz

• Test port: 2-port 50 Ω S-parameter test set

• Dynamic range: 117 dB (spec), 122 dB (typical)

• Trace noise: 0.005 dBrms (spec), 0.002 dBrms (typ.)

• Stability: 0.01 dB/°C

• Source power: –20 to 0 dBm

• Sweep type: Linear & Log frequency, Segment

• NOP: 10,001 points (Max.)

• Channel: 32 channels (Max.)

• Key software capability: Fixture simulator, Time domain analysis/Test Wizard option, Wireless power transfer analysis, and Materials measurement

• Interface: LAN, USB (front 2, rear 4), USBTMC, GPIB4, Handler I/O4

• Display: 10.4 inch multi-touchscreen

• Operating system: Windows 10

• Ordering information:

E5063A-205

E5063A-215

E5063A-235

E5063A-245

E5063A-265

E5063A-285

E5063A-2D5

E5063A-2H5
