KEYSIGHT E36313A Triple Output Power Supply (6V, 10A & 2X 25V, 2A, 160W)

• Power output: 160 W

• Output Rating:

Output 1: 0 to 6 V, 0 to 5 A

Output 2: 0 to 10 V, 0 to 2 A

Output 3: 0 to 10 V, 0 to 2 A

• Ripple & Noise (20 Hz to 20 MHz)

Normal Mode Voltage: <350 µVrms/ 2 mV p-p, < 1 mVrms/ 5 mVpp

Normal mode current: <4 mA rms, <2 mArms, <1 mArms

• Overvoltage protection (OVP): 0.20% +0.1V & 0.20% +0.4 V

• Command processing time: < 10 ms

• Accuracy 12 months (23 ºC ± 5 ºC)

Current 0.05% + 4 mA & 0.04% +3 mA

Voltage 0.03% + 3 mV & 0.03% +5 mV

• AC input: AC 100- 230 V, 600 VA

• includes over voltage, over current, and over temperature protection

• Three independent outputs in one instrument saves maintenance cost and bench space

• Display: 4.3-inch LCD color show the voltage and current of all three channels at the same time

• Included accessories: Power cord, output voltage wire, instruction manual

Datasheet
