KEYSIGHT E36311A Power Supply, Triple-Output (6 V, 5 A & ±25 V, 1 A, 80 W)

Power output: 80 W

Output Rating:

Output 1: 0 to 6 V, 0 to 5 A

Output 2: 0 to +25 V, 0 to 1 A

Output 3: 0 to -25 V, 0 to 1 A

Ripple & Noise (20 Hz to 20 MHz)

Normal Mode Voltage: <350 µVrms/ 2 mV p-p

Normal mode current: <2 mA rms, <500 µA rms

Overvoltage protection (OVP): 0.20% +0.1V & 0.20% +0.4 V

Command processing time: < 10 ms

Accuracy 12 months (23 ºC ± 5 ºC)

Current 0.1% +10 mA & 0.1% +4 mA

Voltage 0.1% +5 mV & 0.05% +10 mV

AC input: AC 100- 230 V, 47- 63 Hz
Interface: USB

includes over voltage, over current, and over temperature protection

Three independent outputs in one instrument saves maintenance cost and bench space

Display: 4.3-inch LCD colorshow the voltage and current of all three channels at the same time

Included accessories: Power cord, output voltage wire, instruction manual
