KEMET T599B686M004ATE090 Automotive Grade Organic Capacitor 4VDC 68uF 1380 20% ESR=90mOhms AEC-Q200
ManufacturerKEMET(View more products from this manufacturer)
ModelT599B686M004ATE090
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
ESR: 90 mOhms
Width: 2.8 mm
Height: 1.9 mm
Length: 3.5 mm
Tolerance: 20 %
Capacitance: 68 uF
Unit Weight: 100 mg
Mfr Case Code: B Case
Qualification: AEC-Q200
Ripple Current: 1.188 A
Leakage Current: 27.2 uA
Termination Style: SMD/SMT
Voltage Rating DC: 4 VDC
Moisture Sensitive: Yes
Dissipation Factor DF: 8
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
