KEMET R75TW327050L3J Automotive DC and Pulse Film Capacitor 1.6k V 0.27 uF 105C 5% 2 Pin LS=37.5 mm AEC-Q200

ESR: 10 mOhms

Width: 15 mm (0.591 in)

Height: 15 mm (0.591 in)

Length: 41.5 mm (1.634 in)

Tolerance: 5 %

Dielectric: Polypropylene (PP)

Lead Style: Straight

Capacitance: 0.27 uF

Lead Spacing: 37.5 mm (1.476 in)

Lead Diameter: 1 mm

Qualification: AEC-Q200

Number of Pins: 2 Pin

Capacitance - nF: 270 nF

Capacitance - pF: 270000 pF

Termination Style: Radial

Voltage Rating AC: 650 VAC

Voltage Rating DC: 1.6 kVDC

Maximum Operating Temperature: + 105 C

Minimum Operating Temperature: - 55 C
