KEMET ELG107M450AS1AV General Purpose Electrolytic Capacitors 450V 100uF 20% 30x25 105C
ManufacturerKEMET(View more products from this manufacturer)
ModelELG107M450AS1AV
Contact
Secure Checkout
Quality Engagement
Easy change and return
Delivery Available
ESR: 628 mOhms
Life: 2000 Hour
Length: 25 mm
Diameter: 30 mm
Tolerance: 20 %
Capacitance: 100 uF
Lead Spacing: 10 mm
Number of Pins: 2 Pin
Ripple Current: 650 mA
Test Frequency: 120 Hz
Leakage Current: 900 uA
Termination Style: Snap In
Voltage Rating DC: 450 VDC
Dissipation Factor DF: 20 %
Maximum Operating Temperature: + 105 C
Minimum Operating Temperature: - 25 C
