KEITHLEY 2200-20-5 Programmable DC Power Supplies

with Remote Sensing
- DC OUTTPUT RATING
+ Voltage: 0 to 20 V
+ Current: 0 to 5 A
+ Max power: 100 W
- LOAD REGUlATION
+ Voltage: <0 01="" 2="" mv="" br=""> + Current: <0 05="" 0="" 1="" ma="" br=""> - LINE REGUlATION
+ Voltage: < 0 .01% + 1 mV
+ Current: <0 05="" 0="" 1="" ma="" br=""> - RIPPlE AND NOISE (20 Hz to 7 MHz)
+ Voltage: <1 mvrms="" 3="" mvp-p="" br=""> + Current: <3 marms="" br=""> - SETTING RESOlUTION
+ Voltage: 1 mV
+ Current: 0 .1 mA
- SETTING ACCURACY
+ Voltage: ±0 .03% + 3 mV
+ Current: ±0 .05% + 2 mA
- READBACK RESOLUTION
+ Voltage: 1 mV
+ Current: 0 .1 mA
- READBACK ACCURACY (25°C ± 5°C)
+ Voltage: 0 .02% + 3 mV
+ Current: ±0 .05% + 2 mA
Interfaces: USB, GPIB
- POWER SOURCE:
+ 110V AC Setting: 99VRMS to 132VRMS .
+ 220V AC Setting: 198VRMS to 264VRMS .
WEIGHT: 7 .3kg .
