KECHENG GT320C High Speed Table Centrifuge (20000 rpm)

Max Speed: 20000rpm

Voltage: AC 220±22V 50Hz 15A

Max RCF: 31115×g

Noise Level: ≤ 60dB（A）

Max Capacity: 4×250ml

Size: 560×570×370mm

Timer: 1s～99h59min

Net Weight: 110kg

Revolutions/min: ±10r/min

Rotor automatic recognition: Yes

Power: 1200W

Rotor parameters：

Angle rotor 1: Rotor Capacity: 16×1.5/2.0ml; Max Speed（r/min): 20000rpm; Max RCF(×g): 30677×g

Angle rotor 2: Rotor Capacity: 24×1.5/2.0ml; Max Speed（r/min): 18000rpm; Max RCF(×g): 31115×g

Angle rotor 3: Rotor Capacity: 12x5ml; Max Speed（r/min): 16000rpm; Max RCF(×g): 17344×g

Angle rotor 4: Rotor Capacity: 12×10ml; Max Speed（r/min): 15000rpm; Max RCF(×g): 20274×g

Angle rotor 5: Rotor Capacity: 32×1.5/2.0ml; Max Speed（r/min): 16000rpm; Max RCF(×g): 26044×g

Angle rotor 6: Rotor Capacity: 48×1.5/2.0ml; Max Speed（r/min): 16000rpm; Max RCF(×g): 27762×g

Angle rotor 7: Rotor Capacity: 12×15ml/Conical bottom; Max Speed（r/min): 14000rpm; Max RCF(×g): 22241×g

Angle rotor 8: Rotor Capacity: 6×50ml/Round bottom); Max Speed（r/min): 13000rpm; Max RCF(×g): 17146×g

Angle rotor 9: Rotor Capacity: 6×50ml (Conical/round bottom); Max Speed（r/min): 12500rpm; Max RCF(×g): 17608×g

Angle rotor 10: Rotor Capacity: 4x100ml; Max Speed（r/min): 12000rpm; Max RCF(×g): 17016×g

Angle rotor 11: Rotor Capacity: 6×100ml; Max Speed（r/min): 12000rpm; Max RCF(×g): 17548×g

Angle rotor 12: Rotor Capacity: 8×50ml(Conical/round bottom); Max Speed（r/min): 10000rpm; Max RCF(×g): 12611×g

Angle rotor 13: Rotor Capacity: 60×1.5ml; Max Speed（r/min): 15000rpm; Max RCF(×g): 18826×g

Swing-out rotor 14: Rotor Capacity: 40×15ml(W); Max Speed（r/min): 5500rpm; Max RCF(×g): 5952×g

Swing-out rotor 15: Rotor Capacity: 4×100ml; Max Speed（r/min): 5000rpm; Max RCF(×g): 3717×g

Swing-out rotor 16: Rotor Capacity: 4×250ml(round bucket); Max Speed（r/min): 5000rpm; Max RCF(×g): 4751×g

Swing-out rotor 17: Rotor Capacity: 4×500ml(oval bucket); Max Speed（r/min): 5000rpm; Max RCF(×g): 4751×g

Swing-out rotor 18: Rotor Capacity: 4×250ml(Square bucket); Max Speed（r/min): 5000rpm; Max RCF(×g): 4751×g

Swing-out rotor 19: Rotor Capacity: Micro-plate 2x2x96 hole; Max Speed（r/min): 4500rpm; Max RCF(×g): 2603×g
