Jumo 608003 Mechanical dial thermometer (0 ~ +80 °C)

Order code: 608003/0110-810-010-10-104-26-100/000

Image may be a representation. See datasheet for product details.

Display range (AB) in °C: 0 to +80

Process connection (PC): TA 01, Protection tube with collar

Ø Process connection (PC): 10 mm

Thread type of process connection (PC): Screw connection G 1/2

Material of process connection (PC): Stainless steel (CrNi, 1.4571)

Insertion length, process connection (PC) dimension "S": 100 mm

Extra code (TZ): Without extra code

The measuring principle of the thermometer is based on a bimetal coil in a stainless steel or brass protection tube. If the temperature increases or falls, it turns and has a direct effect on the indicator via an axis.
