Julabo SW23 Shaking Water Bath (+20 ... +99.9 °C; 20L)

Dimensions and volumes:

Dimensions (W × L × H): 27.6 x 13.8 x 10.2 in.

Filling volume: 8 ... 20 l

Usable immersion depth: 7.1 in.

Weight: 45.6 lbs

Temperature values:

Working temperature range: +20 ... +99.9 °C

Temperature stability: ±0.2 °C

Setting the resolution of the temperature display: 0.1 °C

Ambient temperature 1: +5 ... +40 °C

Performance values: 230V/50Hz (Schuko Plug - CEE 7/4 Plug Type F)

Heating capacity: 2 kW

Power consumption: 9A

Bath:

Bath tank: Stainless steel

Bath cover: accessory

Usable bath opening (W x L / D): 19.7 x 11.8 / 7.1 in.

Waterbath:

Dimension with bathcover (W x L x H): 27.6 x 13.8 x 16.9 in.

Shaking frequency / adjustable Shaking frequency (linear): 20 ... 200 rpm

Shaking stroke / adjustable shaking stroke: 15 mm

Electronics:

Temperature display: LED

Temperature setting: Keypad

Temperature control: PID1
