Capacity of work tank: 2700x1700x800mm
Work table size: 2250x1100mm
Longitudinal travel(X-axis): 2000mm
Cross travel(Y-axis): 1000mm
Z axis travel(Z-axis): 600mm
Distance between platen to table: 660~1260mm
Max. Electrode weight: 500kgs
Max. Work piece weight: 9500kgs
Fluid tank capacity: 3800L
Machine outside dimensions(WxDxH): 5200x4500x3570mm
Machine weight: 12500kgs
Max. Machining current: 90A; 120A(Optional)
Max. Power input: 10KVA; 13KVA
Max. Machining rate: 600; 800 mm3/min
Min. Electrode wear ratio: 0.12%
Best surface / Ra: Ra 0.2μm
Min. D. R. O. resolution(mm): 0.001mm
Generator weight: 350 kgs
