Johoyd LX-CS Shore hardness tester (0–100HD; 0.5 degrees)
Technical Parameters:
Measuring range: 0-100HD
Measurement error: Within 10-90 degrees，error<±1 degrees
Resolution: 0.5 degrees
Needle stroke: 2.5mm
Needle end pressure: 0.55N-8.05N
Needle head size: SR2.5MM
Product size: 115×60×25mm
Weight: About 160g
Product standard and applications:
1. The products are produced according to the ISO 868 and ISO 7619 international standards and meet the standards of GB/T531, JB6148 and JJG304
2. It is suitable for measuring the hardness of an image-molded microporous material made of a foaming agent with a stress of 0.5kg/cm2 or more when the compression rate is 50%, and it can also be used for the hardness test of other materials with similar hardness.
