JINKO JK9902A DC Electronic Load (150V, 2A, 20A, 200W)

Channel: single channel

Input rating:

Voltage: 0~150V

Current: 0~2A, 0~20A

Power: 200W

CV mode:

Range: 0~18V, 0~150V

Resolution ratio: 1mV, 10mV

Precision: ±(0.05%+0.025%FS)

CC mode:

Range: 0~2A, 0~20A

Resolution ratio: 1mA, 10mA

Precision: ±(0.05%+0.05%FS)

CR mode:

Range: 0.05Ω-7.5ΚΩ

Resolution ratio: 16 bit

Precision: 0.1% +0.5%FS

CP mode:

Range: 200W

Resolution ratio: 10mW

Precision: 0.1% +0.5%FS

Dynamic current:

Dynamic mode (T1 & T2): 100µS~3600S

Precision: 5 µS±100 ppm

Rise/Fall slope: 0.001~0.15A/μS

Voltage read-back:

Range: 0~18V, 0~150V

Resolution ratio: 1mV, 10mV

Precision: ±(0.05%+0.1%FS)

Current read-back:

Range: 0~2A, 0~20A

Resolution ratio: 1mA, 10mA

Precision: ±(0.05%+0.1%FS)

Power read-back:

Range: 200W

Resolution ratio: 10mW

Precision: ±(0.1%+0.5%FS)

Basic protection:

Power protection: 202W

Current protection: 20.2A

Voltage protection: 152V

Temperature protection: 85℃

Size: 300mm x 88mm x 174mm

Product Description:

Programmable high-power DC electronic load manufacturer, providing customized solutions to meet your needs
