JINKO JK9320A Withstand Voltage Insulation Tester (0.000-20.00mAAC)

Test function: AC

Measure parameter:

AC: 0.05kV-5.00kV ±(2% rdg+5dgt)(50/60Hz optional)

DC: 0.05kV-6.00kV ±(2% rdg+5dgt)

Voltage regulation: ≤(1.0%+5V)(rated power)

Current test range:

AC: 0.000mA-20.00mA

Test accuracy: ± 2.0% rdg+5dgt

Discharge function: Automatic discharge after the test is over(DCW)

Insulation resistance test:

Output voltage: 0.05kV –1kV ±(2.0% rdg+8dgt)

Discharge function: Automatic discharge after the test is over

Arc Detection:

Measuring range:

AC: 0mA –15mA

DC: 0mA –10mA

Other function:

Voltage rise time: 0.1s –999.9s

Test time(AC/DC): 0.2s –999.9s

Voltage waiting time(IR): 0.2s –999.9s

Time precision: ±(1%+0.1s)

Display: 4.3’’ TFT

Port: PLC, RS232C, USB

Size: W280mm * H88mm * D380mm

Datasheet

Performance characteristics

￭ Three test functions are available: ACW, DCW, IR

￭ 480×272 dots, TFT-LCD display

￭ Output power: AC: 5kV/10mA; DC: 6kV/5mA

￭ Can carry out online test of 100 units at the same time

￭ 20 test steps can be stored, 4 test steps can be connected to the program memory step

￭ Fast communication speed, baud rate up to 19600

￭ Fast discharge and arc detection function

￭ Anti-high voltage electric shock function, the output can be interrupted immediately when the human body accidentally touches it

￭ The test of the power-on self-test function can be used to determine whether each test function is normal before the test.

￭ Front panel software input calibration

￭ Can set calibration time and warning time to remind users

￭ Built-in PLC Remote interface

￭ Keyboard lock function

￭ Security lock function

￭ Small size and light weight

￭ Application: computer peripheral equipment, home appliances, electrical products, communication products, OA products, lighting products, small home appliances, lighting equipment, electronic components, transformers, Motor, compressor, electric heating pipe, wire, cable, etc.
