JINKO JK7500-1200A Portable Dry Block Temperature Furnace (300°C~1200°C)

Temperature Range: 300°C~1200°C

Temperature Source: Heating wire

Display Accuracy: ±0.1°C (Full temperature range)

Stability: ≤±0.3℃

Vertical temperature field: Within 30mm from the bottom of the hole: 10mm≤0.1℃

Horizontal temperature field: ≤±0.3℃

Well depth: 185mm

Diameter of uniform temperature block: 38mm

Calibration hole diameter: Standard: 6mm, 8mm, 10mm, 12mm (can be customized)

Calibration quantity: 4 (can be customized)

Resolution: 0.01°C

Display: LCD (°C or °F)

Control way: Touch screen, automatically adjust power and temperature difference

Heating time: 300°C→1200°C:250min

Cooling time:

1200°C→800°C: 30min,

800°C→300°C: 70min,

300°C→50°C: 180min

Dimension: 330 * 165 * 320 mm

Weight: 10 kgs

Power supply: 230VAC ±10, 15A

Calibration point: -20°C, 0°C, 20°C, 50°C, 100°C, 150°C, 250°C, 350°C, 450°C, 650°C, 1200°C (Reference model)

Work condition: 15°C ~ 60°C, 80% RH

Accessories: Temperature block (aperture 12/10/8/6mm), power cord, high-temperature cotton
