JINKO JK7110 Withstand Voltage Insulation Tester (0～5kV(AC) ±（2%+5V))

Output voltage: 0～5kV(AC) ±(2%+5V)

Upper limit of AC current: 0.10～12.00mA ±(2%+2 dgts)

Lower limit of AC current: 0.00～12.00mA ±(2%+2 dgts)

Liquid crystal display: 16 x 2 row backlight liquid crystal display

Test time: 0.1～999.9s ±（2%+0.05sec)

Remote control device: Input: Test, Reset Output: Pass, Fail, Test-in-Progress

Test alarm: Buzzer, Indicator light

Correction method: Software correction

Memory device: It can memorize voltage, current, resistance, time, and other setting values.

Temperature / humidity: 0°C～40°C≤ 75% RH

Size / weight: W×H×D: 280mm×100mm×370mm / 10kg

Standard accessories: 26002A

Manual

Program controlled withstand volotage insulation tester

Performance characteristics

■ The voltage increases according to the time gradient, looking for analysis breakdown point.

■ Upper and lower limit setting of current

■ Front panel software correction

■ LCD display, menu boot operation

■ Arc detection function (1-9 level)

■ Keyboard locking function

■ 5 groups of measurement and memory patterns

■ The test time, voltage, current and resistance are displayed simultaneously.

■ optional of RS232 and PLC interface

■ Humanized design and simple operation
